Content
|
Q25 |
Q30 |
|
Color |
C M Y K + 2W /C M Y K +4W /C M
Y K Lc Lm + 2W
C M Y K Lc Lm + 2V/C M Y K + 2 W +2 V/2 ( C M Y K L) |
| |
|
Resolution |
800 X 800 dpi |
|
Printing modes and speed
|
Quality mode: 12.6m2/hr (135
ft2/hr)
Production mode: 22.8m2/hr( 245ft2/hr)
High speed mode: 41.0m2/hr ( 441 ft2/hr ) |
Quality mode:10.2m2/hr (110
ft2/hr)
Production mode: 19.4m2/hr ( 209ft2/hr)
High Speed mode: 38.6m2/hr (415 ft2/hr) |
|
Media |
Type |
Rigid & flexible media |
|
|
Size: |
Effective Printing area:
Board: 2.40m X 1.20m
Width for flexible media : 1.80m
Max material Size: 2.42m X 1.22m
Width for flexbile media :1.83m |
Effective Printing area:
Board: 3.0m X 2.0m
Width for flexible media : 1.30m
Max material Size: 3.02m X 2.02m
Width for flexible media :1.37m |
|
Thickness |
Board :≤ 50mm , flexbile media:≤ 1mm |
Board :≤ 50mm , flexbile media:≤ 1mm |
|
Weight |
Board :≤ 35Kg /m2 , flexbile
media:≤ 50Kg/Roll |
|
Ink |
UV
Inks |
|
|
Imagine format file
|
PostscriptR3TM and EPS, TIFF , JPG, PDF ect. |
|
|
Power Specifications
|
AC 380V ± 10%,3 Phase ,50/60
Hz or AC 220V ± 10%, Single Phase 50/60 Hz |
|
Power Consumption |
5.8 KVA (± 12A) for machine and 3.5 KVA (± 7A) for Vacuum System |
5.8 KVA ( ± 12A) for machine and
7.0 KVA (± 14A) for Vacuum system |
|
Workstation and RIP |
Windows XP , Caldera RIP / USBV 2. 0,LAN |
|
|
Options |
1. Roll to roll printing
(Optional), 2. Protective hood (Optional) |
|
Dimension (L X W X H) |
4.61 X 2.85 X 1.58 m |
4.16 X 4.61 X 1.61 m |
|
Net Weight & Gross Weight |
1750 Kg & 2200 Kg |
2600 Kg & 4000 Kg |
|
Package dimensions
|
5.30 X 2.28 X 1.82m |
5.80 X 2.28 X 2.40m |
|
Min Working area |
6.61 X 5.85 X 2.80M |
6.16 X 7.61 X 2.80m |
