Production speeds up to
92m2/h (UV 3200)
-
Double sided backlit
printing option
-
Media handling system
supports rolls up to 340Kg
-
Prints on viny , banner ,
films, paper & fabrics
-
Visible resolution up to 800
dpi
-
fast curing ,
environmentally friendly UV inks
-
Maximum printing width of
3.3m
-
Simultaneous printing
on multiple rolls.
|
|
Technical Specifications |
-
Color : (C M Y K W ) X 2, ( C M Y K ) X 2+Lc+Lm, (C M Y K W ) X
2+Lc+Lm
-
Resolution : Graphic resolution up to 800 dpi
-
Printing modes and Speed:
Ultra
mode: 22m2 / hr (237ft2/hr)
High mode: 45m2/ hr (484ft/hr)
Production mode: 92m2/hr (990 ft2/hr)
-
Printing mode
direction: Uni and Bi-directiona
-
Print operation: Edge to
edge printable
Material type: Flexible materials
-
Materials Thickness: ≤ 1 mm
(0.04inch)
-
Material Weight: ≤ 340 Kg
-
Imaging format file:
postscriptR3TM ,and EPS , TIFF, JPG, PDF ect.
-
Max. printing size: 3300mm
-
Ink type: UV curing ink
-
Power specifications:
AC 380V ± 10% , 3 Phase ,50/60 Hz
-
Power consumption: 6.8 KVA
(≤ 12A ) for machine and 0.75 KVA (≤ 7A) for Vacuum system
-
Workstation and RIP:
Windows XP , Caldera RIP /USB 2.0, LAN
-
Dimension ( L X W X H ) 5.88
X 1.48 X 1.77 m
-
Net weight & Gross weight:
1920 Kg & 2700 Kg
|
|
|
|
